CoralAPI

MIT License Python 3.11+ CI GitHub release (latest by date) GitHub last commit

CoralAPI logo

A FastAPI service that exposes HTTP inference APIs for Google Coral Edge TPUs (PCIe/M.2 and USB). Point it at a Coral, POST an image, get a result — classification, detection, segmentation, pose, embeddings, or the raw output tensors of any .tflite model. Deployable as a Docker container locally or on Kubernetes.

It aims to be the well-supported, modern replacement for aging Coral inference servers (e.g. CodeProject.AI’s Coral path): current Python, a clean REST API, per-request model selection with automatic downloads, and honest handling of the finicky Coral runtime stack.

A Coral TPU is required. There is no CPU fallback — the service fails fast at startup with an actionable error if no Edge TPU is available, so a running instance always means accelerated inference.

Contents

Features

Quickstart

Docker

docker build -t coralapi .                 # AVX2 x86-64 host; see "Build profiles" for others

# PCIe / M.2 module (needs the gasket/apex driver on the host):
docker run --device /dev/apex_0 -p 8000:8000 -v ./models:/models coralapi

# USB Accelerator:
docker run --device /dev/bus/usb -p 8000:8000 -v ./models:/models coralapi

Classify an image — the model downloads on first use:

curl -F file=@cat.jpg \
  "http://localhost:8000/v1/vision/classify?model=tf2_mobilenet_v2_1.0_224_ptq_edgetpu"

Interactive, always-current API docs are served at http://localhost:8000/docs (Swagger UI) and /redoc; the raw schema is at /openapi.json.

From source

Requires uv and an attached Coral (the service won’t start without one):

git clone https://github.com/nathan-v/coralapi.git && cd coralapi
uv sync
CORALAPI_MODEL_DIR=./models uv run uvicorn coralapi.main:app --host 0.0.0.0 --port 8000

Installing tflite-runtime + libedgetpu from PyPI/apt on your own host is version-sensitive — see Build profiles and Troubleshooting. The Docker image bundles a known-good, matched runtime, which is the recommended way to run.

Endpoints & examples

Endpoint Purpose
POST /v1/vision/classify?model=<name> Classify an image → ranked labels
POST /v1/vision/detect?model=<name> Object detection → boxes + labels
POST /v1/vision/segment?model=<name> Semantic segmentation → class mask (PNG) + summary
POST /v1/vision/pose?model=<name> Single-pose keypoints → named (x, y, score)
POST /v1/vision/embed?model=<name> Image embedding → feature vector
POST /v1/raw/infer?model=<name> Any model → raw output tensors
POST /v1/jobs/classify, .../detect Submit async job → 202 + job id
GET /v1/jobs/{id} Poll async job status/result
GET /v1/models List locally available models
GET /v1/status TPU runtime + discovered hardware
GET /v1/queue Queue depth + pending count
POST /v1/reset Rebind the Edge TPU after a device replug (no restart)
GET /metrics Prometheus metrics (when enabled)
GET /healthz Liveness probe — process is up (unversioned)
GET /readyz Readiness probe — the bound TPU is present & unchanged (unversioned)

Every endpoint takes the image as a multipart file field and the model as a model query parameter. Results are JSON. Below is a worked request + response for each.

Classification

curl -F file=@cat.jpg \
  "http://localhost:8000/v1/vision/classify?model=tf2_mobilenet_v2_1.0_224_ptq_edgetpu&top_k=3"

{
  "model": "tf2_mobilenet_v2_1.0_224_ptq_edgetpu",
  "results": [
    {"index": 286, "label": "Egyptian cat", "score": 0.68},
    {"index": 283, "label": "tabby",        "score": 0.12},
    {"index": 282, "label": "tiger cat",    "score": 0.07}
  ]
}

top_k (default 5) caps the number of classes returned. label is null unless a labels file is present (see Models).

Object detection

curl -F file=@street.jpg \
  "http://localhost:8000/v1/vision/detect?model=ssd_mobilenet_v2_coco_quant_postprocess_edgetpu&threshold=0.4"

{
  "model": "ssd_mobilenet_v2_coco_quant_postprocess_edgetpu",
  "results": [
    {"box": [0.11, 0.09, 0.98, 0.76], "index": 16, "label": "cat", "score": 0.95}
  ]
}

box is [ymin, xmin, ymax, xmax] normalized to 0..1 (the TFLite convention). threshold (default 0.4) filters low-confidence detections. Works with SSD and YOLO models (see Models).

Semantic segmentation

curl -F file=@street.jpg \
  "http://localhost:8000/v1/vision/segment?model=deeplabv3_mnv2_pascal_quant_edgetpu"

{
  "model": "deeplabv3_mnv2_pascal_quant_edgetpu",
  "width": 513, "height": 513,
  "classes": [
    {"index": 0,  "label": "background", "pixels": 178956},
    {"index": 15, "label": "person",     "pixels": 84213}
  ],
  "mask_png": "iVBORw0KGgoAAAANS…"
}

mask_png is a base64 PNG (mode L) where each pixel’s value is its class index — decode and reshape client-side (see the Python client). classes lists the classes present, most pixels first.

Pose estimation

curl -F file=@person.jpg \
  "http://localhost:8000/v1/vision/pose?model=movenet_single_pose_lightning_ptq_edgetpu"

{
  "model": "movenet_single_pose_lightning_ptq_edgetpu",
  "keypoints": [
    {"name": "nose",          "x": 0.51, "y": 0.22, "score": 0.94},
    {"name": "left_eye",      "x": 0.53, "y": 0.20, "score": 0.91},
    {"name": "left_shoulder", "x": 0.60, "y": 0.38, "score": 0.88}
  ]
}

x/y are normalized 0..1. 17-keypoint models are named in COCO order (nose, left_eye, …); other counts are named kp0, kp1, …

Image embeddings

curl -F file=@product.jpg \
  "http://localhost:8000/v1/vision/embed?model=mobilenet_v1_1.0_224_quant_embedding_extractor_edgetpu&normalize=true"

{ "model": "…", "dimension": 1024, "normalized": true, "embedding": [0.031, -0.007, 0.052] }

The feature vector, for similarity search, deduplication, or on-device imprinting. normalize=true L2-normalizes it, so cosine similarity is a plain dot product.

Generic / raw inference (any model)

For any model CoralAPI has no dedicated decoder for, POST /v1/raw/infer runs it and returns every output tensor verbatim, for you to decode:

curl -F file=@input.jpg \
  "http://localhost:8000/v1/raw/infer?model=your_custom_model_edgetpu"

{
  "model": "your_custom_model_edgetpu",
  "input_shape": [1, 224, 224, 3],
  "outputs": [
    {
      "name": "output0",
      "shape": [1, 1001],
      "dtype": "float32",
      "quantization": {"scale": 0.00390625, "zero_point": 0},
      "data": [0.001, 0.004, "…"]
    }
  ]
}

data is flattened in row-major (C) order; reshape with shape. Integer outputs are dequantized to float32 by default; pass ?dequantize=false for raw quantized values plus scale/zero_point. Decoding hints for common model types:

Model type Output shape Decode (arr = np.array(out["data"]).reshape(out["shape"]))
Segmentation [1, H, W] or [1, H, W, C] arr[0] (or arr[0].argmax(-1) for per-class logits)
Pose [1, 1, 17, 3] arr[0, 0] → 17 (y, x, score) keypoints
Embeddings [1, D] arr[0] is the vector

Async jobs

For long-running or fire-and-forget calls, submit a job and poll it. Jobs share the same TPU queue as synchronous requests.

# Submit → 202 Accepted with a job id
curl -F file=@cat.jpg \
  "http://localhost:8000/v1/jobs/detect?model=ssd_mobilenet_v2_coco_quant_postprocess_edgetpu"
# {"id":"9f2c…","kind":"detect","model":"…","status":"queued","created_at":1.7e9,"finished_at":null,"error":null,"result":null}

# Poll until status is "succeeded" or "failed"
curl "http://localhost:8000/v1/jobs/9f2c…"
# {"id":"9f2c…","status":"succeeded","result":{"model":"…","results":[{"box":[…],"index":16,"label":"cat","score":0.95}]}, …}

Job results are kept in memory for CORALAPI_JOB_RETENTION_SECONDS (default 1h), then purged. Job state is per-replica — with multiple replicas, poll on the replica that accepted the job (use session affinity).

Errors

Errors are JSON {"detail": "…"} with a status code, and are deliberately generic (internal detail is logged server-side, not returned):

Status Meaning
400 Uploaded file is not a decodable image
404 Unknown model (not local and not downloadable)
413 Upload exceeds the size or resolution limit
429 TPU queue is full — retry later
502 Model download from the source failed
503 Inference runtime unavailable

Python client

A runnable client with a helper per endpoint (including mask/keypoint decoding) lives at examples/client.py:

from examples.client import CoralAPI

api = CoralAPI("http://localhost:8000")

print(api.classify("cat.jpg", "tf2_mobilenet_v2_1.0_224_ptq_edgetpu", top_k=3))
print(api.detect("street.jpg", "ssd_mobilenet_v2_coco_quant_postprocess_edgetpu"))

mask = api.segment_mask("street.jpg", "deeplabv3_mnv2_pascal_quant_edgetpu")  # -> (H, W) numpy array
vec = api.embed("product.jpg", "mobilenet_v1_1.0_224_quant_embedding_extractor_edgetpu", normalize=True)

Run it directly against a live server: python examples/client.py http://localhost:8000 cat.jpg.

Models

Any Edge TPU-compiled .tflite model works — drop it in the model directory (CORALAPI_MODEL_DIR) or let the service download it by name on first use. Classification, detection, segmentation, pose, and embeddings have dedicated decoders; anything else runs through /v1/raw/infer.

Model selection & download. The model parameter is a file stem (no .tflite). If <name>.tflite isn’t in the model directory, it’s fetched from CORALAPI_MODEL_SOURCE/<name>.tflite (HTTPS only, no redirects), cached, and reused. Set CORALAPI_MODEL_DOWNLOAD=false to serve only local models.

Labels. For recognized zoo models the correct shared label file — coco_labels.txt, imagenet_labels.txt, inat_bird_labels.txt, PASCAL segmentation, etc. — is auto-fetched alongside the model (guessed from the model name), so label is populated with no setup. Precedence: a per-model <name>.labels.txt (or <name>.txt) you supply wins over the guess; a shared labels.txt is the final fallback. For a custom model CoralAPI can’t recognize, drop a <name>.labels.txt in the model directory — otherwise results still return with label: null (and models like face/pose/embeddings have no class labels by design).

Known-working models (as of July 2026)

Verified present in the default source (google-coral/test_data) — pass the name without .tflite; it downloads on first use.

Classification (/v1/vision/classify, labels: imagenet_labels.txt unless noted):

Object detection (/v1/vision/detect, labels: coco_labels.txt unless noted — use the _postprocess/_ptq variants that include the NMS postprocess; _no_nms variants are not supported):

The detection decoder auto-detects the postprocess output order, so both the TF1 (boxes, classes, scores, count) layout and the TF2 Object Detection API’s reversed (boxes, scores, classes, count) layout decode correctly.

Segmentation (/v1/vision/segment): deeplabv3_mnv2_pascal_quant_edgetpu, deeplabv3_mnv2_dm05_pascal_quant_edgetpu, keras_post_training_unet_mv2_128/256_quant_edgetpu.

Pose (/v1/vision/pose): movenet_single_pose_lightning_ptq_edgetpu, movenet_single_pose_thunder_ptq_edgetpu.

Embeddings (/v1/vision/embed): the *_embedding_extractor_edgetpu models and tfhub_tf2_resnet_50_imagenet_ptq_edgetpu.

YOLO

Ultralytics YOLO models (v8/11/26) run on Coral via their Edge TPU export:

yolo export model=yolo11n.pt format=edgetpu   # → yolo11n_full_integer_quant_edgetpu.tflite

The raw YOLO head (no built-in NMS) is decoded server-side, so the export works with /v1/vision/detect as-is. YOLO exports aren’t in the default source — drop the file into the model directory alongside an 80-class COCO <model>.labels.txt.

Configuration

All settings are environment variables prefixed CORALAPI_:

Variable Default Meaning
CORALAPI_MODEL_DIR /models Directory scanned for *.tflite models
CORALAPI_DEVICE auto Which Edge TPU: auto, usb, pci, or a specific index (pci:0, pci:1, usb:0) to pin one instance to one TPU — see Multiple TPUs
CORALAPI_MODEL_SOURCE Coral test_data mirror Base URL for model downloads (must be https)
CORALAPI_MODEL_DOWNLOAD true Disable to serve only local models
CORALAPI_ALLOW_INSECURE_MODEL_SOURCE false Permit a non-HTTPS model_source (not recommended)
CORALAPI_MAX_DOWNLOADED_MODELS 100 Cap on models cached to disk via download (count)
CORALAPI_MAX_MODEL_BYTES 268435456 (256 MB) Per-model download size cap; an over-size download is aborted
CORALAPI_MAX_MODEL_CACHE_BYTES 4294967296 (4 GB) Total model-cache size cap; a download over it is refused
CORALAPI_MODEL_CHECKSUMS {} Optional JSON {name: sha256}; a listed model’s download is verified
CORALAPI_QUEUE_DEPTH 16 Requests allowed to wait for the TPU (else 429)
CORALAPI_JOB_RETENTION_SECONDS 3600 How long finished async job results are pollable
CORALAPI_MAX_UPLOAD_BYTES 524288000 (500 MB) Request-body size limit (413 beyond; enforced at the ASGI layer)
CORALAPI_UPLOAD_DIR <tmp>/coralapi-uploads Directory streamed uploads are written to
CORALAPI_MAX_IMAGE_DIM 15360 (16K) Longest allowed image edge in pixels
CORALAPI_ALLOWED_IMAGE_FORMATS [] (any) Optional JSON list of decoded formats to accept (e.g. ["JPEG","PNG"]); others get 415
CORALAPI_MAX_VIDEO_DIM 15360 (16K) Reserved for the planned video endpoints
CORALAPI_EDGETPU_LIB unset Override the libedgetpu shared-library path
CORALAPI_METRICS_ENABLED false Expose Prometheus metrics at /metrics

Build profiles (CPU / architecture)

libedgetpu and tflite_runtime must be built against compatible TFLite versions, and prebuilt tflite wheels target a CPU instruction set — an AVX2 wheel crashes (SIGILL) on a pre-Haswell CPU. Pick a profile for your target by overriding two build args (current URLs are in the Dockerfile header):

Profile Target Build
avx2 (default) x86-64 with AVX2 (Intel Haswell / 2013+, most modern CPUs) docker build -t coralapi .
compat x86-64 without AVX2 (e.g. Sandy/Ivy Bridge Xeon) --build-arg TFLITE_SPEC=tflite-runtime==2.14.0 --build-arg LIBEDGETPU_DEB=<feranick 2.13.1 std .deb> --build-arg LIBEDGETPU_SHA256=4ffb6c2251b61535afb6b368d821211a914d2d4783770ec7e6001c073c2d193b
arm Raspberry Pi (armhf) --platform linux/arm/v7 plus the armhf LIBEDGETPU_DEB and armv7l TFLITE_SPEC wheel, each with its matching LIBEDGETPU_SHA256 / TFLITE_SHA256

Not sure whether your CPU has AVX2? Run grep -o avx2 /proc/cpuinfo — no output means use compat.

Whenever you override LIBEDGETPU_DEB or point TFLITE_SPEC at a wheel URL, also pass the matching LIBEDGETPU_SHA256 / TFLITE_SHA256 (get it with sha256sum). The build verifies every downloaded artifact against the pinned checksum and fails on a mismatch, so a stale default checksum stops the build rather than silently installing the wrong binary.

The default (avx2) uses the feranick matched pair (libedgetpu + tflite_runtime at the same TF version — the reliable pairing rule, since no formal compatibility matrix is published). The compat profile pairs Google’s PyPI tflite-runtime 2.14.0 (built without AVX2) with feranick’s nearest libedgetpu (2.13.1) — verified working end-to-end on a no-AVX2 Xeon. See Troubleshooting if inference fails.

Monitoring

Set CORALAPI_METRICS_ENABLED=true to expose Prometheus metrics at GET /metrics (the image bundles prometheus-client; for a source install add the prometheus extra). Alongside the default process/Python collectors:

Metric Type Labels
coralapi_inferences_total counter operation, model, status (ok or the HTTP status)
coralapi_inference_duration_seconds histogram operation, model (successful requests)
coralapi_queue_pending gauge — (running or waiting for the TPU)
coralapi_queue_depth gauge — (configured limit)
coralapi_models_loaded gauge — (models held on the TPU)

/metrics is unauthenticated like the rest of the API — scrape it from within the cluster, behind the gateway.

Security model

The service ships without authentication or rate limiting — deploy it behind an authenticated gateway/ingress and add per-client rate limiting there. Given that posture, it still bounds unauthenticated resource use and avoids leaking internals:

To report a vulnerability, see SECURITY.md.

Kubernetes

See deploy/k8s/deployment.yaml. The pod needs the TPU device node — the manifest assumes a device plugin (e.g. generic-device-plugin) exposing /dev/apex_0 as squat.ai/apex; a privileged hostPath fallback is included commented out. The TPU device node must be group-accessible to the non-root runtime user (supplementalGroups). Scale replicas with the number of TPUs (one inference in flight per TPU); async job state is in-memory, so use session affinity when scaling out.

Multiple TPUs

The engine drives one TPU at a time (one dedicated thread, thread-affine delegates), so to use several Coral TPUs on one host — e.g. a dual-PCIe card — run one instance per TPU, each pinned to a specific device with CORALAPI_DEVICE:

docker run --device /dev/apex_0 -e CORALAPI_DEVICE=pci:0 -p 8000:8000 -v ./models:/models coralapi
docker run --device /dev/apex_1 -e CORALAPI_DEVICE=pci:1 -p 8001:8000 -v ./models:/models coralapi

On Kubernetes, run one replica per TPU — each with a different CORALAPI_DEVICE and its device assigned by the device plugin — behind a single Service for round-robin load balancing. This gives N× throughput using the proven single-TPU path per pod. (Driving multiple TPUs from a single process is a possible future enhancement; the current recommendation is one instance per TPU.)

How it works

A request flows through a fixed pipeline:

  1. Upload — the multipart body streams to a temp file in bounded chunks (never fully in memory); the size limit is enforced at the ASGI layer before the body is read, and the image’s dimensions are validated from its header before any pixels are decoded.
  2. Queue — the work is submitted to the TPU executor, a single dedicated worker thread. The Edge TPU runs one inference at a time, and libedgetpu delegates are thread-affine, so all TPU work — model loading and every inference — happens on that one thread. Requests beyond CORALAPI_QUEUE_DEPTH waiting are rejected with 429.
  3. Model load — registry.get(name) returns a cached, loaded model, or downloads (<source>/<name>.tflite) and loads it on first use. Each model gets its own Edge TPU delegate.
  4. Inference + decode — the image is resized to the model’s input tensor, the interpreter runs, and a task-specific decoder (classify/detect/segment/pose/embed) or the raw tensor dump shapes the JSON response.

Startup loads the Edge TPU delegate once to verify a working TPU is present — if not, the process exits with an actionable error (no CPU fallback by design). Sync endpoints wait for the result; async job endpoints reserve a queue slot immediately (so a full queue is rejected at submit time) and run the work in the background for polling.

Device binding & recovery. The delegate is bound to a specific device at startup, so an unplug/replug leaves it stale. /readyz records the device present at bind time and returns 503 if the device is later missing or re-enumerated (so Kubernetes pulls the pod from the Service), while /healthz (liveness) stays up so a transient replug doesn’t kill the pod. POST /v1/reset rebinds without restarting: on the TPU thread it drops the loaded models (releasing their stale delegates) and re-acquires the device, so the next inference runs fresh.

Adding a new task type is small and uniform: a decoder method on the model + a response schema + a thin endpoint reusing the shared pipeline.

Troubleshooting

Most issues are the Coral runtime stack, not the API. The service’s GET /v1/status reports the interpreter in use and the hardware it discovered — check it first.

Symptom Cause & fix
Startup: RuntimeError: Coral Edge TPU unavailable … Hardware discovered: none No TPU reached the process. Confirm the device is attached and passed through (--device /dev/apex_0 for PCIe, --device /dev/bus/usb for USB); for a non-root container the device node must be group-accessible (--group-add, or supplementalGroups in K8s).
Container exits with code 132 SIGILL — an AVX2-compiled tflite wheel on a CPU without AVX2. Rebuild with the compat build profile.
Inference 500s; logs show EdgeTpuDelegateForCustomOp failed to invoke libedgetpu and tflite_runtime were built against incompatible TFLite versions. Use a matched pair (the Docker profiles do this); don’t mix, e.g., Google’s apt libedgetpu with a modern tflite-runtime.
Logs show numpy.core.multiarray failed to import tflite-runtime’s C extension needs numpy 1.x; numpy 2.x breaks it. The image pins numpy<2 — if you hit this in a source install, pin it yourself.
404 Unknown model The model name is wrong, or it isn’t in CORALAPI_MODEL_SOURCE and isn’t a local file. Check GET /v1/models and the name (no .tflite).
502 model download failed The server couldn’t reach CORALAPI_MODEL_SOURCE (no egress, or the file 404s upstream). Check network egress from the container.
429 queue full Too many concurrent requests for one TPU. Raise CORALAPI_QUEUE_DEPTH, add TPUs/replicas, or slow the caller.
Results have "label": null No labels file for the model. Add <model>.labels.txt (or a shared labels.txt) to the model directory — see Models.
USB Coral stops being found after re-plugging The USB Accelerator re-enumerates with a new address after an unplug/replug, leaving the loaded delegate stale. Pass the whole bus (--device /dev/bus/usb), not a single device path. /readyz returns 503 while the device is gone or changed; POST /v1/reset rebinds it without restarting the process (or just restart the pod).

Development

uv sync                     # install all dependencies (dev group included)
uv run pytest               # hardware-independent test suite (the TPU delegate is mocked)
uv run ruff check .         # lint
uv run ruff format .        # format
uv run uvicorn coralapi.main:app --reload   # run locally — needs a TPU attached

The test suite mocks the Edge TPU, so it runs anywhere (no Coral or libedgetpu needed) and is what CI runs. See CONTRIBUTING.md for the workflow.

License

MIT — see LICENSE.

This site is open source. Improve this page.
