Clockd

MIT License Python 3.11+ CI GitHub release (latest by date) GitHub last commit

Clockd logo

Clockd is a simple API service that estimates vehicle speeds from security camera video clips.

It uses YOLO object detection, ByteTrack tracking, and perspective correction to produce per-vehicle speed estimates in JSON.

Quick Start

pip install -e .
uvicorn clockd.main:app
# http://localhost:8000/health

Or with Docker:

docker compose up clockd-cpu

API

Method Path Description
GET /health Health check
GET /cameras List configured cameras
GET /cameras/{id} Get camera config
POST /cameras Create camera config
PUT /cameras/{id} Update camera config
DELETE /cameras/{id} Delete camera config
POST /process Process video (multipart upload)
GET /jobs List async jobs
GET /jobs/{id} Get job status/results
DELETE /jobs/{id} Delete completed/failed job
POST /calibrate/preview Overlay ROI + detections on a frame
POST /calibrate/warp Bird’s-eye perspective transform view
POST /calibrate/extract-frame Extract a single frame from a video
POST /calibrate/speed-test Auto-calibrate with a known-speed video
GET /calibrate/ui Interactive point-and-click calibration UI

Processing a Video

curl -F file=@clip.mp4 -F camera_id=front_yard http://localhost:8000/process

For async processing:

curl -F file=@clip.mp4 -F camera_id=front_yard -F async_mode=true http://localhost:8000/process
# Returns {"job_id": "...", "status": "pending"}
# Poll: curl http://localhost:8000/jobs/<job_id>

Camera Configuration

Each camera needs a calibration profile that maps pixel coordinates to real-world measurements. Configs live in configs/cameras/*.yaml and can also be managed via the API.

camera_id: "front_yard"
description: "Front yard camera, ~90 degrees to road"
resolution: [1920, 1080]    # Expected video resolution [width, height]

calibration:
  source_points:            # 4 pixel corners of the road region in the video
    - [100, 400]
    - [700, 400]
    - [900, 700]
    - [50, 700]
  target_width_m: 8.0       # Real-world width of that region in meters
  target_height_m: 40.0     # Real-world height of that region in meters

roi_polygon: null            # Optional detection zone (defaults to source_points)
model_override: null         # Optional YOLO model override (e.g. "yolov8m.pt")
confidence_override: null    # Optional confidence threshold override
min_detections: 10           # Minimum detections to report a valid speed
min_displacement_m: 0.0      # Minimum real-world travel (meters); 0 disables
smoothing_window: 5          # Moving average window for position smoothing
speed_calibration_factor: 1.0  # Multiply all speeds by this value
speed_range:                 # Discard speeds outside this range
  min_mph: 3.0
  max_mph: 150.0

Calibration Tuning Tool

Use the calibration endpoints to visually verify your camera config before processing videos.

Preview - shows your ROI polygon, labeled source points, and detected vehicles on a camera frame:

# With vehicle detection (default)
curl -F file=@frame.jpg -F camera_id=front_yard http://localhost:8000/calibrate/preview -o preview.png

# Without detection (just ROI overlay)
curl -F file=@frame.jpg -F camera_id=front_yard -F detect=false http://localhost:8000/calibrate/preview -o preview.png

Warp - shows the bird’s-eye perspective-transformed view with a 1-meter grid overlay:

curl -F file=@frame.jpg -F camera_id=front_yard http://localhost:8000/calibrate/warp -o warp.png

The warp view should show a rectangular top-down view of the road. If it looks distorted or the grid spacing seems wrong, adjust your source_points or real-world dimensions.

Extract a frame from a video (so you don’t need ffmpeg):

curl -F file=@clip.mp4 http://localhost:8000/calibrate/extract-frame -o frame.png

# Or grab a specific frame (e.g. frame 100)
curl -F file=@clip.mp4 -F frame_number=100 http://localhost:8000/calibrate/extract-frame -o frame.png

Interactive UI - open http://localhost:8000/calibrate/ui in a browser to click 4 points on your camera frame and generate the config visually. The UI lets you drag-and-drop an image, click the road corners, set dimensions, and either copy the YAML or create the camera directly via the API.

Generate a Camera Config with AI

Setting up source_points and real-world measurements can be tricky. You can use an LLM like Claude to generate the config for you. This may not work as well as using the config UI but YMMV.

What to provide:

  1. A screenshot/frame from your camera (so the LLM can identify the road and estimate pixel coordinates)
  2. A Google Maps satellite link centered on the camera location (so the LLM can measure real-world road width and calibration zone length)
  3. Basic details: camera ID, resolution, and mounting info

Prompt:

I need to create a camera calibration config for Clockd, a vehicle speed estimation system. The config maps a trapezoidal road region in the camera frame to real-world meter dimensions using a perspective transform.

Here is a frame from my security camera: [attach screenshot]

Here is a Google Maps satellite view of the road the camera is pointed at: [paste Google Maps link]

Camera details:

Please generate a YAML camera config with these fields:

camera_id: "<id>"
description: "<description>"
resolution: [<width>, <height>]   # video resolution in pixels

calibration:
  source_points:        # 4 pixel coordinates [x, y] forming a trapezoid around the road
    - [x1, y1]          # top-left of road region
    - [x2, y2]          # top-right
    - [x3, y3]          # bottom-right
    - [x4, y4]          # bottom-left
  target_width_m: <w>   # real-world width of the road region in meters
  target_height_m: <h>  # real-world depth/length of the road region in meters

roi_polygon: null
model_override: null
confidence_override: null
min_detections: 10       # minimum frames a vehicle must be tracked
smoothing_window: 5      # moving average for position noise reduction
speed_range:
  min_mph: 3.0           # ignore below (parked/creeping vehicles)
  max_mph: 150.0         # ignore above (tracking glitches)

For source_points: identify the road surface in the camera frame and pick 4 corners that form a trapezoid covering the section of road where vehicles travel. The top edge should be further away, the bottom edge closer to the camera. Points must be at the camera’s native resolution.

For target_width_m and target_height_m: use the Google Maps satellite view to measure the real-world width of the road and the depth (along the direction of travel) of the region covered by the source points. These values directly determine speed accuracy.

For speed_range: set max_mph based on the road type (residential ~45, highway ~85). Set min_mph to 3-5 to filter out parked cars that jitter.

Why Google Maps helps: The camera image gives pixel coordinates but no sense of scale. The satellite view lets the LLM measure actual road width (typically 3-4m per lane) and estimate the length of the calibration zone, which directly determines speed accuracy.

Accuracy Tips

Speed accuracy depends primarily on calibration quality and camera setup. Here’s what matters most:

Camera placement (biggest impact):

Video settings:

Calibration:

Speed calibration:

If reported speeds are consistently off, use speed_calibration_factor to correct them without re-doing your calibration:

  1. Drive past the camera at a known GPS-verified speed (e.g. 25 mph)
  2. Process the clip and note the reported speed (e.g. 32 mph)
  3. Set speed_calibration_factor to actual / reported (25 / 32 = 0.78)
  4. Update the camera config via PUT /cameras/{id}

All speeds for that camera will be multiplied by this factor. Do 2-3 passes at different speeds to confirm the error is consistent before setting it. Default is 1.0 (no adjustment).

Filtering settings:

Grafana Dashboard

A pre-built Grafana dashboard is included at grafana/clockd-dashboard.json. Import it via Dashboards > Import > Upload JSON. It requires an InfluxDB v2 datasource configured with the Flux query language.

Panels: vehicle speed (max/avg/min), vehicles detected, processing time, speed distribution histogram, detection confidence, HTTP requests, and request duration.

Configuration

Server settings in configs/server.yaml or via CLOCKD_ environment variables:

Setting Default Description
host 0.0.0.0 Bind address
port 8000 Bind port
detection_backend local "local", "roboflow", "localai", "codeproject_ai", or "coralapi"
detection_fallback none "local" to fall back to local CPU inference when a remote backend is unreachable
model yolo26n.pt Default YOLO model (local backend only)
confidence 0.3 Detection confidence threshold
default_unit mph Speed unit (mph or kmh)
max_upload_mb 200 Max upload size
max_workers 2 Async job thread pool size
cameras_dir configs/cameras Camera configs directory
max_cameras 50 Max camera configs the API will create via POST /cameras

Environment variables take precedence over server.yaml. Nested settings use __ as the delimiter, which lets you keep secrets (NVR passwords, InfluxDB tokens) out of the config file entirely and inject them at deploy time — e.g. from a Kubernetes Secret:

CLOCKD_METRICS__INFLUXDB_V2__TOKEN=...
CLOCKD_EVENT_SOURCES__HOME_NVR__UNIFI__USERNAME=clockd-user
CLOCKD_EVENT_SOURCES__HOME_NVR__UNIFI__PASSWORD=...

A complete hardened Kubernetes deployment (secrets via env vars, non-root, read-only root filesystem, dropped capabilities) is provided at deploy/k8s-example.yaml.

Detection Backends

Local (default) - runs YOLO locally via ultralytics. Supports CPU and GPU. No external dependencies beyond the Python packages.

YOLO Model Selection

Models auto-download on first use. Pick based on your hardware:

Model Speed Accuracy Best for
yolo26n.pt (default) Fastest Good CPU, Raspberry Pi
yolo26s.pt Fast Better Moderate CPU or any GPU
yolo26m.pt Medium Great GPU with 4GB+ VRAM
yolo26l.pt Slow Excellent GPU with 8GB+ VRAM
yolo26x.pt Slowest Best Beefy GPU, max accuracy

YOLOv8, v9, v10, v11, and v12 variants are also supported. For security camera footage where vehicles are typically large in frame, nano or small is usually sufficient - calibration accuracy has more impact on speed estimates than model size.

Set globally in server.yaml via model, or per-camera via model_override.

Remote Detection Backends

All remote backends offload detection to an external server. Clockd sends each frame and receives bounding boxes back. Tracking, perspective transform, and speed calculation still run locally. The model and model_override settings are ignored - the model is configured on the remote server.

Backend Comparison
Backend Models GPU Coral TPU OS Status Best for
Local (default) YOLO v8/v9/v10/v11/v12/26 CUDA No Any Ultralytics (very active) Simplest setup, no extra services
Roboflow Inference YOLO v8/v10/v11/26, RF-DETR, YOLO-NAS CUDA + TensorRT No Linux, macOS Very active (daily commits) GPU server, best model selection
LocalAI RF-DETR CUDA, ROCm, Vulkan No Linux, macOS, Windows Very active (monthly releases) Already running LocalAI for LLMs
CodeProject.AI YOLOv5, v8, v11 CUDA Yes (YOLOv5 TFLite) Windows, Linux, macOS Slow (last release Dec 2024) Raspberry Pi + Coral TPU
coralapi Edge TPU .tflite (SSD MobileNet, EfficientDet) No (TPU only) Yes (native) Linux Active Dedicated Coral TPU, lowest power

Notes:

Backend Configuration

Roboflow Inference:

detection_backend: "roboflow"

roboflow:
  url: "http://your-gpu-server:9001"
  model_id: "yolo11n-640"   # any alias from inference docs
  timeout: 30

Start the server: pip install inference-cli && inference server start

LocalAI:

detection_backend: "localai"

localai:
  url: "http://localhost:8080"
  model: "rfdetr-base"
  timeout: 30

CodeProject.AI:

detection_backend: "codeproject_ai"

codeproject_ai:
  url: "http://localhost:32168"
  timeout: 30

coralapi:

detection_backend: "coralapi"

coralapi:
  url: "http://localhost:8000"
  model: "ssd_mobilenet_v2_coco_quant_postprocess_edgetpu"
  timeout: 30
  resize_max_px: 640   # optional; Edge TPU models run at ~300px anyway

Start the server (Coral Edge TPU required): see the coralapi quickstart.

Event Sources (NVR Integration)

Clockd can automatically poll your NVR for vehicle detection events, download clips, and process them — no external automation needed.

UniFi Protect

Add to configs/server.yaml:

event_sources:
  home_nvr:
    enabled: true
    camera_map:
      "aabbccddeeff00112233aabb": "front_yard"  # Protect camera ID -> clockd camera_id
    unit: "mph"
    unifi:
      host: "192.168.1.1"
      username: "clockd-user"
      password: "your-password"
      verify_ssl: false       # Protect uses self-signed certs
      poll_interval_s: 30     # seconds between polls
      event_end_timeout_s: 300  # max wait for event to end

Find your Protect camera ID in the Protect web UI URL: https://protect.local/cameras/<camera_id>.

The camera_map maps Protect camera IDs to clockd camera config names. Only mapped cameras are monitored. Multiple event sources can be configured for different NVR instances.

The poller authenticates to Protect, watches for vehicle smart-detection events, waits for each event to end, downloads the clip, and submits it through the standard processing pipeline. Results are available via the jobs API and flow through any configured metrics exporters.

Adding Other NVR Sources

The event source system is modular. To add support for Frigate, ZoneMinder, or another NVR:

  1. Create src/clockd/services/event_sources/your_nvr.py implementing the EventSource base class (start, stop, name)
  2. Add a config model to config.py
  3. Add a branch in the create_event_source() factory in manager.py

No changes needed to the processing pipeline, job manager, or metrics.

Security Notice

Clockd does not include authentication, authorization, or rate limiting. It is designed to run on a trusted local network. If you need to expose it beyond your LAN, place it behind a reverse proxy (e.g. Nginx, Caddy, Traefik) that handles TLS, authentication, and rate limiting. The default Docker Compose config binds to 127.0.0.1 for this reason.

See SECURITY.md for vulnerability reporting and known limitations.

Development

pip install -e ".[dev]"
pytest
